| Part number | Photo | Size | Operation direction | Pulse | Detent | Push-on switch | Shaft type | Downloads |
|---|---|---|---|---|---|---|---|---|
| E1100EX1V2 |  |
11mm | Horizontal | 15/20 pulse | Optional | Without | Optional |  |
| E1100WX3W1 |  |
11mm | SMT | 15/20 pulse | Optional | Yes | Optional | |
| E1101XX1H1 |  |
11mm | Vertical | 15/20 pulse | Optional | Yes | Optional | |
| E1101WX3W1 |  |
11mm | SMT | 15/20 pulse | Optional | Without | Optional | |
| E1105ZX3W1 |  |
11mm | Vertical | 15 | 30 | Without | Optional | |
| E1105XX1H1 | |
11mm | Vertical | 15/20 pulse | Optional | Without | Optional | |
| E1120XX1H1 |  |
11mm | Vertical | 15/20 pulse | Optional | Without | Optional | |
| E1121XX1H1 |  |
11mm | Vertical | 15/20 pulse | Optional | Without | Optional | |
| E1130XX1H1 |  |
11mm | Vertical | 15/20 pulse | Optional | Without | Optional | |
| E1130XX1V2 |  |
11mm | Horizontal | 15/20 pulse | Optional | Yes | Optional | |
| E1131EX1V1 |  |
11mm | Horizontal | 15/20 pulse | Optional | Yes | Optional | |
| E1131XX1H1 |  |
11mm | Vertical | 15/20 pulse | Optional | Yes | Optional | |
| E1200AX0H1 |  |
12mm | Vertical | Optional | Optional | Without | Optional | |
| E1200CX0V1 |  |
12mm | Horizontal | 12/24 | 12/24 | Without | Optional | |
| E1200JX0V1 |  |
12mm | Horizontal | 12/24 | 12/24 | Without | Optional | |
| E1200XX0H1 |  |
12mm | Vertical | 12/24 | 12/24 | Without | Optional | |
| E1201AX1H1 |  |
12mm | Vertical | 12/24 | 12/24 | Without | Optional | |
| E1201DX3W1 |  |
12mm | SMT | 12/24 | 12/24 | Yes | Optional | |
| E1230XX1H1 |  |
12mm | Vertical | 12/24 | 12/24 | Without | Optional | |
| E1231XX1H1 |  |
12mm | Vertical | 12/24 | 12/24 | Yes | Optional | |
| E1600AE0H1 |  |
16mm | Vertical | 24 | 24 | Without | Optional | |
| E1600AE0H1 |  |
16mm | Vertical | 24 | 24 | Without | Optional | |
| E1600BG0V1 |  |
16mm | Horizontal | 24 | 24 | Without | Optional | |
| E1800AA1H1 |  |
18mm | Vertical | 24 | 24 | Without | Optional | |
| E1801AA1H1 |  |
18mm | Vertical | 24 | Optional | Without | Optional | |
| E1802AA1H1 |  |
18mm | Vertical | 12 | 24 | Without | Optional | |
| E2100AX1H1 |  |
21mm | Vertical | 15 | 30 | Without | N/A | |
| E2500AX1H1 |  |
25mm | Vertical | 10 | 20 | Without | N/A | |
| E2802AX1H1 |  |
28mm | Vertical | 15 | 30 | Without | N/A | |
| E3500AX3H1 |  |
35mm | Vertical | 10 | 30 | Without | N/A | |
