SS400TTFS1

Part number	SS400TTFS1
Structure	case, display screen , hollow encoder
Actuator configuration
Actuator length
Number of detent	30

Number of pulse
Push-on switch	Yes
Travel of push-on switch
Operating temperature range	-20℃-70 ℃

Electrical characteristics
	Ratings
	Output signal
	Max./min. operating current (Resistive load)
	Insulation resistance
	Voltage proof

Mechanical characteristics
	Rotational torque	50,000
	Push-pull strength

Push-on switch specifications
	Contact arrangement
	Travel
	Operating force	260gf ±30gf
	Ratings
	Contact resistance (Initial performance/After lifetime)
	Operating life	50,000 cycles

Durability	Operating life	50,000 cycles
MOQ		2000 pcs


Wave soldering
	Soldering surface temperature
	Heating time
	Soldering temperature
	Soldering time
	No. of solders

This site catalog shows only outline specifications. When using the products, please obtain formal specifications for supply.
Please place purchase orders per minimum order unit (integer).
Products other than those listed in above products are also available. Please contact us for details.
"L" in the "Lever Wobble" column of the above table indicates the length of lever.
This products can be used in vehicles.
Although these products are designed to perform over a wide operating temperature range, please ensure that you receive and read the formal delivery specifications before use.
