English Mechanical characteristics |
||
|---|---|---|
| Total rotational angle： | 45°±3° （one step operating angle) | |
| Rotational torque： | 200-500 gf.cm | |
| Rotational stopper strength： | 6.0 kg. cm max | |
| Push-pull strength： | shaft play in axial direction 0.4 max | |
| Shaft wobble： | 0.7*L/30mm p-p Max | |
| Bushing nut tighten strength： | 7.0Kgf.cm Min | |
| Shaft play in shaft direction： | 0.4mm Max | |
| Shaft play in rotational wobble： | 5° max | |
| Click torque： | ||
|
|
|
|
Electrical characteristics |
||
|---|---|---|
| Rated power： | DC 16V 3A Max | |
| Poles： | 1 | |
| Sections： | 5 | |
| Voltage proof： | 300V AC for 1 min. or 360V AC for 2s | |
|
|
|
|
Durability |
||
|---|---|---|
| Salt mist： | In the temperature of 35°C ±2°C and concentration of 5±1% for 8H then clean with water | |
| Rotational life： | 10，000cycle | |
|
|
|
|
